GENERAL
Authentication Method Secure Shell v.2 (SSH2)
Authentication Method Secure Shell v.2 (SSH2)
Encryption Algorithm DES, Triple DES, AES
Routing Protocol OSPF, RIP-1, RIP-2, BGP, EIGRP
MODEM
Type DSL modem
Digital Signaling Protocol SHDSL
POWER DEVICE
Power Provided 50 Watt
Nominal Voltage AC 120/230 V
Frequency Required 50/60 Hz
Type internal power supply
CAMERA
Installed Size 32 MB
NETWORKING
Form Factor desktop
Type Router
Connectivity Technology wired
Data Link Protocol Ethernet, Fast Ethernet
Network / Transport Protocol IPSec
Features DiffServ support, Dynamic Multipoint VPN (DMVPN), load balancing, Intrusion Prevention System (IPS), Network Admissions Control (NAC), Quality of Service (QoS), Stateful Packet Inspection (SPI), URL filtering, VLAN support, VPN support, firewall protection
Compliant Standards IEEE 802.1Q, IEEE 802.1x
Routing Protocol BGP, EIGRP, OSPF, RIP-1, RIP-2
Switching Protocol Ethernet
Remote Management Protocol HTTP, SNMP
COMMUNICATIONS
Digital Signaling Protocol SHDSL
MISCELLANEOUS
Rack Mounting Kit optional
Encryption Algorithm AES, DES, Triple DES
Height (Rack Units) 1 m
Refurbished refurbished
INTERFACE PROVIDED
Type management, modem, network
Interface Ethernet 10Base-T/100Base-TX, ISDN BRI ST, SHDSL, auxiliary, console
Qty 1, 8
Connector Type RJ-45
WAN / DMZ WAN
RAM
Max Supported Size 384 MB
Technology SDRAM
FLASH MEMORY
Max Supported Size 128 MB
SOFTWARE / SYSTEM REQUIREMENTS
Type Cisco IOS Advanced IP services
ENVIRONMENTAL PARAMETERS
Min Operating Temperature 32 °F
Max Operating Temperature 104 °F
Humidity Range Operating 10 - 85%
HEADER
Brand Cisco
Product Line Cisco
Model 1812
Packaged Quantity 1
Compatibility PC
DIMENSIONS & WEIGHT
Width 12.8 in
Depth 9.7 in
Height 1.8 in
Weight 6.17 lbs
EXPANSION SLOTS
Type memory
Total Qty 1
Free Qty 0
PERFORMANCE
Type VPN throughput (3DES IPSec)
Value 40 Mbps
